Technical parameter

Rated power

7KW

Charging gun

Single

Display mode

4.3-inch display (without touch)

Charging mode

RFID card, optional scanning code

Charging mode

autofill

Installation mode

Wall hanging, column type

ammeter

Integrated onboard electric meter

Lightning protection

Integrated on-board lightning protection

Input

Input voltage (V)

220Vac±15%

Input phase current (A)

32A

Ac input Frequency (HZ)

45～55

Output

Output voltage range (V)

220Vac±15%

Rated output phase current (A)

32A

PWM duty cycle

53.3%

Maximum output power (kW)

7kW

Gun length (m)

3.5m

Protective characteristic

Output short-circuit protection

No output after protection, unrecoverable (manual recovery required)

Output overcurrent protection

No output after protection, unrecoverable (manual recovery required)

Output overvoltage protection

No output after protection, can be restored (no manual recovery)

Input undervoltage protection

Reduced power after protection, recoverable (no manual recovery required)

PWM exception protection

No output after protection, unrecoverable (manual recovery required)

Scram protection

No output after protection, unrecoverable (manual recovery required)

Ac leakage protection

No output after protection, unrecoverable (manual recovery required)

Connection exception protection

After protection, there is no output and can be restored

Safety characteristic

Withstand voltage test voltage (input-chassis)

2000Vac 1min 10mA

Withstand voltage test voltage (output - chassis)

2000Vac 1min 10mA

Input insulation resistance to chassis (DC500V)

≥10MΩ（Atmospheric relative humidity 90%, no condensation)

Output insulation resistance to chassis (DC500V)

≥10MΩ (Atmospheric relative humidity 90%, no condensation)
